Scot Pump 1500GPH 115/230V 50/60hz

Price: $925.00
No reviews yet Write a Review
SKU:
35066-2
Shipping:
Calculated at Checkout

Scot Pump 1500GPH 115/230V 50/60hz

 Scot Model: 35066-2 with a 3 inch impeller - Replaces Oberdorfer model 104M / P1500BXT

Pump

  • All Bronze marine centrifugal pump
    Freshwater or seawater applications
  • Precision machined to close tolerances
    for consistent performance.
  • Hardware - Type 300 stainless steel
  •  Semi-open impeller handles solids to
    5/16 inch (7mm)
  • Impeller mounted on motor shaft
  • Heavy-duty, designed for continuous
    24 hour – 7 day operation

Shaft Seal

  • Rated at 75 PSI – 5 BAR
  •  Seawater Buna rubber parts, ceramic
    stationary and carbon rotating element,
    stainless steel spring and metal components.

Motor – 2 Pole

  • Meets Coast Guard ignition protected
    requirements. The thermal protector and starting
    switch are in the enclosed outlet cover.
  • Sealed ball bearings
  • Single-phase capacitor start
    50 Hz - 110/220 Volt 60 Hz – 115/230 Volt
  • Dual frequency 50 Hz or 60 Hz single phase
    motors are available
  • Stainless steel shaft.
  •  Three phase motors are not available.

Performance

Dimensions

Spare Parts



Voltage:
Dual Voltage 115V/230V
Capacity:
Up to 72,000 BTU
