Dometic CU-100 ColdMachine™ Self-Seal QC, AirCooled, 12VDC
Dometic CU Adler Barbour Boat refrigeration units are built to withstand extreme conditions. Even with humid and hot conditions, with erratic voltage or low voltage and constant use, these units have proven to offer extraordinary performance.
The new Dometic CU-100 ColdMachine is 25% more efficient than the models it replaces. The CU-100 can be pared with a Dometic VD Series Evaporator or holdover power plate for a cold storage box or compartment that can be installed as far as 15ft away.
Features
- Self-sealing quick-connect fittings for easy installation
- Corrosion-resistant stainless steel mounting plate
- Can be used for refrigerator capacities up to approx. 424 L
- Optimal performance in warmer waters
- Air-cooled operation
- Shrouded forced-air condenser for added efficiency
Specifications:
| Cold Storage Volume | 15.0 cu. ft. (424 liters) |
| Voltage DC | 12/24 |
| Application | Tropical-Water Boating/General Boating |
| Refrigerant Type | 134A |
| Net Weight (lbs/kg) | 17/7.8 |
| Gross Weight (lbs/kg) | 20/9.1 |
Compatible Evaporators:
| Legacy Part Number | New Part Number | Description | Image |
| 755500000 | 9600026331 | VD-150 small vertical evap. W/O door, self-seal QC |  |
| 755510000 | 9600026332 | VD-151, small horizontal evap. W/door, self-seal QC |  |
| 755520000 | 9108777975 | VD-152 large vertical evap. W/O door, self seal QC |  |
| 755530000 | 9108777977 | VD-153 large horizontal evap. W/door, self-seal QC |  |
| 755560000 | 9108777978 | VD-160 Power plate evap. W/analog thermostat, self-seal QC |  |
| 293600973 | 9108848624 | VD-160 Tubeset, QD's, One shot |  |
